TB-66-O/CASE

Open-out casement window system (thermally broken)

The system is glazed internally to accommodate 24mm or 26mm double glazed units, using standard beads. As with all Brital systems the Open Out Casement window system is manufactured to exacting standards, enabling economy to be combined with strength to give many years of aesthetic, trouble-free operation.


DOWNLOAD AREA


Ask for more information
on this product

SIZE

– Corners formed as 45 degree mitres to provide a
quality appearance, high performance and weather
resistance

DESIGN

– Corners formed as 45 degree mitres to provide a
quality appearance, high performance and weather
resistance.
– Designed to perform at wind resistances up to 2.4 kPa.

PERFORMANCE

– The system offers high quality thermally broken
sections to suit specific project requirements
and reduce heat gain.
– Thermal performance can achieve Uw of 1.6 W/m2K.

INSTALLATION

– Windows are hung on heavy duty fixed hinges with
concealed multi-locking system for effective weather
resistance and security.

PRODUCT DETAILS

The basic suite has Iong leg outer frame section to allow the window to be fitted at the back of the reveal. Also included in the basic suite of profiles are a range of vent and mullion/transoms sections. Various other profiles can be designed and incorporated allowing architects to achieve flexible designs. The system is glazed internally to accommodate 24mm or 26mm double glazed units, using standard beads. As with all Brital systems the Open Out Casement window system is manufactured to exacting standards, enabling economy to be combined with strength to give many years of aesthetic, trouble-free operation.
